Name: Resistant To Acid And Alkali X Tend Cable Mesh Zoo Aesthetic Bird Cage
Brand: Anping Yuntong Metal Wire Mesh Co.,Ltd
SKU: Yt --f
Price: 26.00 USD
Availability: InStock

Resistant To Acid And Alkali X Tend Cable Mesh Zoo Aesthetic Bird Cage

Podstawowe informacje

Miejsce pochodzenia:	Hebei
Nazwa handlowa:	Yuntong
Orzecznictwo:	CE , SGS
Numer modelu:	Yt --f

Minimalne zamówienie:	10 m2
Cena:	USD 2-50
Szczegóły pakowania:	Film opakowany na każdy kawałek, kilka sztuk zapakowanych w 1 karton
Czas dostawy:	5-8 DNI ROBOCZYCH
Zasady płatności:	T/T, Western Union, PayPal
Możliwość Supply:	300 m2/tydzień

Skontaktuj się teraz

Nazwa produktu:

Siatka kablowa X-tend

Słowo klucz:

Siatka kablowa ze stali nierdzewnej

Tworzywo:

AISI316, AISI316L

Lina stalowa:

1,2 mm do 4,0 mm

Konstrukcje linowe:

7 x 7, 7 x 19, 1 x 19

Gotowy:

Kąpiel ultradźwiękowa, tlenek czarny

Orientacja siatki:

Poziome, pionowe

Kąt siatki:

60 stopni

Podkreślić:

acid-resistant bird cage

alkali-resistant zoo aesthetic cage

X Tend cable mesh bird enclosure

Resistant To Acid And Alkali X Tend Cable Mesh Zoo Aesthetic Bird Cage

X Tend Cable Mesh is made of stainless steel wire. The material of the wire is stainless steel: 201.304, 304L, 316, 316L, etc. Hot and cold galvanized steel wire rope can also be used as required.Two conventional types of stainless steel rope mesh.

The x-tend cable mesh is manufactured in the standard diameters 1.0 mm, 1.5 mm, 1.6mm, 2.0 mm, 3.0 mm and 3.2mm. Mesh width of 25 to 200 mm (or bigger) are possible depending on cable diameter.
Rope Mesh is manufactured from high-grade stainless steel cables of material class 1.4401, AISI316.

Mesh connections (ferrules) are available in highly aesthetic stainless steel for premium applications or where resistance to corrosion is a driving consideration.

Finished diamond mesh style when it is stretched at 60 degree angle ;

Mesh can be applied in either a vertical or horizontal direction, again dependent on the balustrade or railing design and the required aesthetics.

X Tend Cable Mesh Specifications Sheet :

Hole Size (Opening)	1.2MM(3/64) (7 x 7 )	1.6MM(1/16) (7 x 7 )	2.0MM(5/64) (7 x 7 )	2.4MM(3/32) (7 x 7 )	3.2MM(1/8) (7 x 19 )
20 x 35mm	YT-1235
25 x 42mm	YT-1225	YT-1625
30 x 52mm	YT-1230	YT-1630	YT-2030
35 x 60mm	YT-1235	YT-1635	YT-2035
38 x 66mm	YT-1238	YT-1638	YT-2038	YT-2438
40 x 69mm	YT-1240	YT-1640	YT-2040	YT-2440	YT-3040
50 x 86mm	YT-1250	YT-1650	YT-2050	YT-2450	YT-3050
60 x 104mm	YT-1260	YT-1660	YT-2060	YT-2460	YT-3060
70 x 120mm	YT-1270	YT-1670	YT-2070	YT-2470	YT-3070
76 x 131mm	YT-1276	YT-1676	YT-2076	YT-2476	YT-3076
80 x 138mm	YT-1280	YT-1680	YT-2080	YT-2480	YT-3080
90 x 154mm	YT-1290	YT-1690	YT-2090	YT-2490	YT-3090
100 x 173mm	YT-12100	YT-16100	YT-20100	YT-24100	YT-30100
120 x 206mm	YT-12120	YT-16120	YT-20120	YT-24120	YT-30120

Material of X Tend Cable Mesh

1. Material of Exhibition Flexible Ferrule Stainless Steel Wire Rope Mesh : Stainless steel 304,304L,316,306L etc.
2. Ferrules Material of Exhibition Flexible Ferrule Stainless Steel Wire Rope Mesh : Tinned-copper, Nickel-plated copper, Stainless steel etc.
3. Cable construction and Diameter of X-tend Cable Mesh : 7x7 (Dia.: 1.2 - 2.5mm), 7x19 (Dia.: 3.0 - 4.0mm)

SS304	(%) C:≤0.07, Si :≤1.0, Mn :≤2.0, Cr :17.0-19.0, Ni :8.0-11.0, S :≤0.03, P :≤0.035
SS316	(%) C:≤0.08, Si:≤1.00, Mn:≤2.00, P≤:0.035, S:≤0.03, Ni:10.0-14.0, Cr:16.0-18.5
SS316L	(%)C:≤0.03, Si:≤1.00, Mn:≤2.00, P:≤0.045, S:≤0.030, Cr:16.0～18.0, Ni:12.0～15.0
